Proxmox GPU Script updated
Yikes is my bottom line at the moment.
There is a significant issue with Kernel 7 and various Nvidia graphics cards. Mine is rather dated which is becoming a problem.
Reasons for script review
- Kernel 7 is breaking the Nvidia passthrough and other stuff
- Kernel updated within the 6.17 branch
- Minor issues in relation to removing old kernels
- A more robust and slightly tuned code
GPU Script for Host setup
Please find below the script. This has been refined on updated with every problem discovered on the updating of the Proxmox host over time.
Updates are a manual affair as I have learned this the hardway.
#!/bin/bash
# -------------------------------------------------------------------------------------
# setup-gpu-pxe.sh - Proxmox VE NVIDIA Driver Installer + LXC GPU Passthrough + Kernel Guard
# -------------------------------------------------------------------------------------
# VERSION: 4.2.1
# UPDATED: 2026-07-20
# CREATED: see git history - github.com/Braedach
# TARGET: Proxmox VE 9.x (Debian 13 / Trixie) | NVIDIA RTX 3070 or similar
# AUTHOR: braedach / Leon
#
# PURPOSE
# Installs NVIDIA drivers on the Proxmox HOST (Debian-packaged, trixie-backports),
# wires up LXC GPU passthrough, and GUARDS the host against the kernel-series jump
# that breaks NVIDIA DKMS. Modules live on the host only; containers bind-mount the
# /dev/nvidia* nodes. NEVER install the NVIDIA driver inside an LXC.
#
# WHY THE GUARD EXISTS (2026-06)
# A routine 6.17 SECURITY update pulled in a whole new kernel series (7.0, Ubuntu
# 26.04 base) via the proxmox-default-kernel meta. NVIDIA 550 does not build on 7.0
# (Debian validates only up to Linux 6.19), so the DKMS build failed mid-apt, wedged
# dpkg, and left a bootable-but-broken 7.0 kernel as the GRUB default. The guard
# turns that silent break into a loud, deliberate decision.
#
# THE GUARD - THREE INDEPENDENT LAYERS
# 1 PREFLIGHT (--preflight) Simulates full-upgrade; BLOCKS if an unapproved kernel
# series would install. Run BEFORE every apt full-upgrade.
# 2 APT HOLDS (--apply-guard) Holds the selector metas + unapproved-series packages.
# Surgical: approved-series security point-updates still flow.
# 3 BOOT PIN (--apply-guard) Pins the running kernel (only if it has a built NVIDIA
# module) so a bad kernel can never boot.
# Only series in APPROVED_KERNEL_SERIES (below) are allowed. Editing that list is how
# you approve a new series - on purpose, after confirming NVIDIA builds against it.
#
# COMMANDS
# (none) Full install (drivers, nodes, service) then apply guard
# --preflight Gate an upgrade BEFORE apt (exit 2 = blocked)
# --apply-guard Apply holds + pin the running kernel
# --remove-guard Lift holds (after approving a new series)
# --guard-status Approved series, holds, pin, kernels, stale boot entries
# --repoint-selector [VER] Move proxmox-default-kernel/headers to an approved-series
# version (the "get off 7.0 as default" fix) + re-hold
# --cleanup-boot Reconcile ESP + remove stale boot entries + refresh
# --prune-dkms Remove DKMS builds for kernels no longer installed
# --check-only System + GPU + guard health
# --force-rebuild Force DKMS rebuild
# --lxc-config ID Print LXC dev* passthrough snippet
# --purge Remove all NVIDIA components (leaves holds)
# --dry-run Preview any action --help Show help
#
# KERNEL UPDATE SOP (manual, production) - run ONE step at a time, review each
# IMPORTANT: the boot pin means a new kernel does NOT auto-boot after an upgrade.
# Pin the NEW kernel BEFORE rebooting so a SINGLE reboot lands on it. (Rebooting
# first just boots the OLD pinned kernel and wastes a reboot.)
#
# 1. apt update
# 2. sudo ./setup-gpu-pxe.sh --preflight
# Gate. If it prints BLOCKED, STOP - an unapproved kernel series is incoming.
# 3. apt full-upgrade
# Installs the new kernel; DKMS builds NVIDIA against it.
# (Use full-upgrade, never plain 'upgrade', on Proxmox.)
# 4. dkms status
# Confirm the NEW kernel shows 'installed'. Do this while STILL on the OLD
# kernel. If it did not build, do NOT reboot - investigate first.
# 5. proxmox-boot-tool kernel pin <NEW-KERNEL>
# Re-pin to the new kernel BEFORE rebooting.
# 6. reboot
# 7. uname -r
# Confirm you are now on <NEW-KERNEL>.
# 8. sudo ./setup-gpu-pxe.sh --check-only
# Verify the GPU is healthy on the new kernel.
# 9. sudo ./setup-gpu-pxe.sh --apply-guard
# Reconfirm apt holds and the boot pin for the running (new) kernel.
# 10. Start passthrough LXCs, then run nvidia-smi inside each.
#
# Optional cleanup, once the new kernel is proven and a spare kernel remains:
# sudo ./setup-gpu-pxe.sh --prune-dkms # drop DKMS builds for removed kernels
# sudo ./setup-gpu-pxe.sh --cleanup-boot # clear stale boot entries
#
# ARCHITECTURE (detail in git)
# P1 Driver : nvidia-kernel-dkms + nvidia-driver + nvidia-persistenced (backports),
# pve-headers, nouveau blacklisted, Secure Boot/MOK handled.
# P2 Nodes : nvidia-setup-nodes.service creates /dev/nvidia-uvm* at sysinit
# (Before=lxc/pve-container) so LXC binds real char devices, not stubs.
# P3 LXC : modern dev* syntax (print_lxc_config is authoritative).
# Files: /etc/systemd/system/nvidia-setup-nodes.service, /usr/local/sbin/nvidia-setup-nodes.sh,
# /etc/udev/rules.d/71-nvidia-uvm.rules, /etc/modprobe.d/blacklist-nouveau.conf,
# /etc/modules-load.d/nvidia.conf
#
# CHANGELOG (full history: github.com/Braedach)
# 4.2.1 (2026-07-20) - Bugfix: --help printed raw escape codes (\033[...]). Colour
# variables now use $'...' C-quoting (real ESC bytes) so they render in the
# cat-heredoc help as well as in echo -e output.
# 4.2.0 (2026-07-20) - Clearer maintenance docs + ASCII-only + DKMS pruning.
# + Rewrote the KERNEL UPDATE SOP to match real practice: because the boot pin
# holds you on the current kernel, you must pin the NEW kernel BEFORE rebooting
# so ONE reboot lands on it. The old doc implied a single reboot moved you
# automatically, which it does not (it boots the old pinned kernel).
# + --prune-dkms: removes DKMS builds for kernels no longer installed, never the
# running kernel. Automates the manual 'dkms remove <mod> -k <old-kernel>'.
# + Replaced all non-ASCII characters (em dashes, smart quotes) in comments and
# runtime messages with plain ASCII.
# 4.1.0 (2026-07-13) - Post-incident cleanup helpers: --repoint-selector, --cleanup-boot,
# stale-boot reporting in --guard-status / --check-only.
# 4.0.0 (2026-06-13) - Kernel-series guard (preflight, holds, boot pin); check-only
# warm-up fix. 3.6.0 - DKMS self-heal + explicit persistenced. Earlier in git.
# -------------------------------------------------------------------------------------
set -euo pipefail
IFS=$'\n\t'
SCRIPT_VERSION="4.2.1"
SCRIPT_NAME="$(basename "$0")"
# -------------------------------------------------------------------------------------
# KERNEL SERIES POLICY (edit APPROVED_KERNEL_SERIES to approve a new series)
# -------------------------------------------------------------------------------------
# Only kernel series listed here are allowed to be installed/followed. A series
# is the X.Y portion of a proxmox kernel package, e.g. "6.17" or "7.0".
# Add a new series ONLY after confirming NVIDIA builds against it (see header).
APPROVED_KERNEL_SERIES=("6.17")
# -------------------------------------------------------------------------------------
# CONFIGURATION CONSTANTS
# -------------------------------------------------------------------------------------
UVM_RULE_FILE="/etc/udev/rules.d/71-nvidia-uvm.rules"
NOUVEAU_BLACKLIST="/etc/modprobe.d/blacklist-nouveau.conf"
MODULES_LOAD_FILE="/etc/modules-load.d/nvidia.conf"
NODE_SCRIPT="/usr/local/sbin/nvidia-setup-nodes.sh"
NODE_SERVICE="/etc/systemd/system/nvidia-setup-nodes.service"
LXC_VIDEO_GID=44 # 'video' group on Debian systems
# Selector meta-packages that decide which kernel series is the default.
SELECTOR_PACKAGES=(proxmox-default-kernel proxmox-default-headers)
# -------------------------------------------------------------------------------------
# FLAGS (set by argument parsing)
# -------------------------------------------------------------------------------------
DRY_RUN=0
PURGE=0
FORCE_REBUILD=0
CHECK_ONLY=0
LXC_CONFIG_ONLY=0
PREFLIGHT_ONLY=0
APPLY_GUARD_ONLY=0
REMOVE_GUARD_ONLY=0
GUARD_STATUS_ONLY=0
CLEANUP_BOOT_ONLY=0
REPOINT_SELECTOR_ONLY=0
REPOINT_VERSION=""
PRUNE_DKMS_ONLY=0
LXC_VMID=""
# -------------------------------------------------------------------------------------
# COLOUR / LOGGING
# -------------------------------------------------------------------------------------
RED=$'\033[0;31m'; YELLOW=$'\033[0;33m'; GREEN=$'\033[0;32m'
CYAN=$'\033[0;36m'; BOLD=$'\033[1m'; RESET=$'\033[0m'
info() { echo -e "${GREEN}[INFO]${RESET} $*"; }
warn() { echo -e "${YELLOW}[WARN]${RESET} $*" >&2; }
error() { echo -e "${RED}[ERROR]${RESET} $*" >&2; }
section() { echo -e "\n${BOLD}${CYAN}=== $* ===${RESET}"; }
ok() { echo -e " ${GREEN}[ok]${RESET} $*"; }
fail() { echo -e " ${RED}[x]${RESET} $*"; }
skip() { echo -e " ${YELLOW}[-]${RESET} $*"; }
run() {
if [[ "${DRY_RUN}" -eq 1 ]]; then
echo -e " ${CYAN}[dry-run]${RESET} $*"
else
eval "$@"
fi
}
# -------------------------------------------------------------------------------------
# KERNEL SERIES HELPERS
# -------------------------------------------------------------------------------------
# Extract the X.Y series from a proxmox kernel/header package name.
# proxmox-kernel-6.17.13-13-pve -> 6.17
# proxmox-kernel-7.0.6-2-pve -> 7.0
# proxmox-kernel-6.17 -> 6.17 (series meta-package)
# proxmox-default-kernel -> "" (selector; handled separately)
kernel_series_from_pkg() {
local pkg="$1" rest=""
rest="${pkg#proxmox-kernel-}"
if [[ "$rest" == "$pkg" ]]; then
rest="${pkg#proxmox-headers-}"
fi
if [[ "$rest" == "$pkg" ]]; then
echo ""
return
fi
echo "$rest" | grep -oE '^[0-9]+\.[0-9]+' || true
}
is_approved_series() {
local s="$1" a
for a in "${APPROVED_KERNEL_SERIES[@]}"; do
[[ "$s" == "$a" ]] && return 0
done
return 1
}
# -------------------------------------------------------------------------------------
# PREREQUISITES
# -------------------------------------------------------------------------------------
check_root() {
[[ "$(id -u)" -eq 0 ]] || { error "Must run as root. Use: sudo $0 $*"; exit 1; }
}
check_prerequisites() {
section "Checking Prerequisites"
local missing=()
for cmd in systemctl apt apt-mark dpkg dpkg-query wget lspci modprobe dkms mokutil; do
if command -v "$cmd" &>/dev/null; then
ok "$cmd found"
else
fail "$cmd missing"
missing+=("$cmd")
fi
done
# mokutil and proxmox-boot-tool are optional
if [[ ${#missing[@]} -gt 0 ]]; then
local required_missing=()
for m in "${missing[@]}"; do
[[ "$m" != "mokutil" ]] && required_missing+=("$m")
done
if [[ ${#required_missing[@]} -gt 0 ]]; then
error "Required tools missing: ${required_missing[*]}"
error "Install with: apt install -y ${required_missing[*]}"
exit 1
fi
fi
}
# -------------------------------------------------------------------------------------
# GPU DETECTION
# -------------------------------------------------------------------------------------
detect_nvidia_gpu() {
section "Detecting NVIDIA GPU"
local gpu_list
gpu_list="$(lspci | grep -iE '(vga|3d|display)' || true)"
if echo "$gpu_list" | grep -qi nvidia; then
local nvidia_line
nvidia_line="$(echo "$gpu_list" | grep -i nvidia | head -1)"
ok "NVIDIA GPU detected: ${nvidia_line}"
if [[ "$(echo "$gpu_list" | wc -l)" -gt 1 ]]; then
info "All display controllers detected:"
while IFS= read -r line; do
info " $line"
done <<< "$gpu_list"
fi
return 0
else
error "No NVIDIA GPU found via lspci."
info "lspci output:"
echo "$gpu_list"
exit 1
fi
}
# -------------------------------------------------------------------------------------
# DEBIAN SOURCES - NON-FREE + TRIXIE-BACKPORTS
# -------------------------------------------------------------------------------------
ensure_debian_sources() {
section "Ensuring Debian Sources (non-free + trixie-backports)"
local sources_file="/etc/apt/sources.list"
local needs_update=0
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would verify non-free and trixie-backports in apt sources"
return
fi
if grep -rq 'non-free-firmware' /etc/apt/sources.list /etc/apt/sources.list.d/ 2>/dev/null; then
ok "non-free-firmware already in sources"
else
warn "non-free-firmware not found in apt sources"
warn "Adding to ${sources_file} - review if this causes issues"
if ! grep -q 'deb.debian.org/debian trixie' "${sources_file}" 2>/dev/null; then
echo "" >> "${sources_file}"
echo "# Added by setup-gpu-pxe.sh for NVIDIA drivers" >> "${sources_file}"
echo "deb http://deb.debian.org/debian trixie main contrib non-free non-free-firmware" >> "${sources_file}"
ok "Added Debian trixie non-free line to ${sources_file}"
else
if grep 'deb.debian.org/debian trixie' "${sources_file}" | grep -qv 'non-free'; then
warn "Found trixie line without non-free - please add non-free non-free-firmware manually:"
warn " Edit: ${sources_file}"
warn " Change: 'deb http://deb.debian.org/debian trixie main'"
warn " To: 'deb http://deb.debian.org/debian trixie main contrib non-free non-free-firmware'"
else
ok "non-free appears to be present in trixie sources"
fi
fi
needs_update=1
fi
if grep -rq 'trixie-backports' /etc/apt/sources.list /etc/apt/sources.list.d/ 2>/dev/null; then
ok "trixie-backports already in sources"
else
info "Adding trixie-backports to ${sources_file}..."
echo "" >> "${sources_file}"
echo "# Added by setup-gpu-pxe.sh - required for NVIDIA drivers on kernel 6.17+" >> "${sources_file}"
echo "deb http://deb.debian.org/debian trixie-backports main contrib non-free non-free-firmware" >> "${sources_file}"
ok "trixie-backports added"
needs_update=1
fi
if [[ "$needs_update" -eq 1 ]]; then
apt_update
fi
}
# -------------------------------------------------------------------------------------
# APT HELPERS WITH RETRY
# -------------------------------------------------------------------------------------
apt_update() {
local attempt max_attempts=3 delay=5
for ((attempt=1; attempt<=max_attempts; attempt++)); do
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] apt-get update"
return 0
fi
info "apt-get update (attempt ${attempt}/${max_attempts})..."
if DEBIAN_FRONTEND=noninteractive apt-get update -qq; then
return 0
fi
warn "apt update failed (attempt ${attempt}). Retrying in ${delay}s..."
sleep "$delay"
delay=$((delay * 2))
done
error "apt-get update failed after ${max_attempts} attempts."
return 1
}
download_with_retry() {
local url="$1" dest="$2"
local attempt max_attempts=3 delay=5
for ((attempt=1; attempt<=max_attempts; attempt++)); do
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] wget -q -O '${dest}' '${url}'"
return 0
fi
info "Downloading: $(basename "$url") (attempt ${attempt}/${max_attempts})..."
if wget -q --timeout=60 -O "$dest" "$url"; then
ok "Downloaded: $(basename "$url")"
return 0
fi
warn "Download failed (attempt ${attempt}). Retrying in ${delay}s..."
sleep "$delay"
delay=$((delay * 2))
done
error "Failed to download: $url after ${max_attempts} attempts."
return 1
}
# -------------------------------------------------------------------------------------
# NOUVEAU BLACKLIST
# -------------------------------------------------------------------------------------
write_nouveau_blacklist() {
cat > "${NOUVEAU_BLACKLIST}" << 'BLEOF'
blacklist nouveau
options nouveau modeset=0
BLEOF
}
blacklist_nouveau() {
section "Blacklisting Nouveau Driver"
if [[ -f "$NOUVEAU_BLACKLIST" ]]; then
ok "nouveau already blacklisted"
return
fi
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would write ${NOUVEAU_BLACKLIST}"
return
fi
write_nouveau_blacklist
ok "nouveau blacklisted"
update-initramfs -u -k all 2>/dev/null || true
}
# -------------------------------------------------------------------------------------
# SECURE BOOT CHECK
# -------------------------------------------------------------------------------------
check_secure_boot() {
section "Checking Secure Boot"
if ! command -v mokutil &>/dev/null; then
skip "mokutil not available - skipping Secure Boot check"
return
fi
local sb_state
sb_state="$(mokutil --sb-state 2>/dev/null || echo "unknown")"
if echo "$sb_state" | grep -qi "SecureBoot enabled"; then
warn "Secure Boot is ENABLED."
warn "NVIDIA DKMS modules must be signed to load."
warn "If modules fail to load after install, enrol a MOK key:"
warn " openssl req -new -x509 -newkey rsa:2048 -keyout /root/mok.key"
warn " -out /root/mok.crt -days 3650 -subj /CN=NVIDIA-DKMS-MOK/ -nodes"
warn " mokutil --import /root/mok.crt"
warn " (reboot, enrol key in MOK manager, then reboot again)"
else
ok "Secure Boot: ${sb_state}"
fi
}
# -------------------------------------------------------------------------------------
# INSTALL NVIDIA DRIVERS FROM TRIXIE-BACKPORTS
# -------------------------------------------------------------------------------------
install_nvidia_backports() {
section "Installing NVIDIA Drivers (trixie-backports)"
local pkgs_needed=()
if dpkg -l pve-headers 2>/dev/null | grep -q '^ii'; then
ok "pve-headers already installed"
else
pkgs_needed+=(pve-headers)
fi
if dpkg -l nvidia-kernel-dkms 2>/dev/null | grep -q '^ii'; then
ok "nvidia-kernel-dkms already installed"
else
pkgs_needed+=(nvidia-kernel-dkms)
fi
if dpkg -l nvidia-driver 2>/dev/null | grep -q '^ii'; then
ok "nvidia-driver already installed"
else
pkgs_needed+=(nvidia-driver)
fi
if dpkg -l nvidia-persistenced 2>/dev/null | grep -q '^ii'; then
ok "nvidia-persistenced already installed"
else
pkgs_needed+=(nvidia-persistenced)
fi
if [[ ${#pkgs_needed[@]} -eq 0 ]]; then
info "All NVIDIA driver packages already installed."
return
fi
info "Installing from trixie-backports: ${pkgs_needed[*]}"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] apt-get install -t trixie-backports -y ${pkgs_needed[*]}"
return
fi
local attempt max_attempts=3 delay=5
for ((attempt=1; attempt<=max_attempts; attempt++)); do
info "Installing (attempt ${attempt}/${max_attempts})..."
if DEBIAN_FRONTEND=noninteractive apt-get install -t trixie-backports -y -qq "${pkgs_needed[@]}"; then
ok "NVIDIA driver packages installed from trixie-backports"
return 0
fi
warn "Install failed (attempt ${attempt}). Retrying in ${delay}s..."
apt_update
sleep "$delay"
delay=$((delay * 2))
done
error "Failed to install NVIDIA driver packages after ${max_attempts} attempts."
error "Check: apt-get install -t trixie-backports nvidia-kernel-dkms nvidia-driver"
return 1
}
# -------------------------------------------------------------------------------------
# DKMS STATUS CHECK + RUNNING-KERNEL SELF-HEAL
# -------------------------------------------------------------------------------------
build_dkms_all_kernels() {
section "Verifying DKMS Build"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would verify DKMS status and autoinstall for running kernel if needed"
return
fi
local running_kernel
running_kernel="$(uname -r)"
info "Running kernel: ${running_kernel}"
info "DKMS status:"
local dkms_out
dkms_out="$(dkms status 2>/dev/null || true)"
if [[ -z "$dkms_out" ]]; then
warn "No DKMS modules registered yet."
else
while IFS= read -r line; do
if echo "$line" | grep -q "installed"; then
ok "$line"
else
warn "$line"
fi
done <<< "$dkms_out"
fi
if echo "$dkms_out" | grep -F "$running_kernel" | grep -q "installed"; then
ok "nvidia DKMS module installed for running kernel ${running_kernel}"
return 0
fi
warn "No installed nvidia DKMS module for running kernel ${running_kernel}"
warn "Attempting 'dkms autoinstall' to build it now..."
if dkms autoinstall 2>&1 | tee /tmp/dkms_autoinstall.log; then
if dkms status 2>/dev/null | grep -F "$running_kernel" | grep -q "installed"; then
ok "DKMS module built for running kernel ${running_kernel}"
else
warn "autoinstall ran but module still not shown installed for ${running_kernel}"
warn "If you just updated the kernel, REBOOT into it and re-run --check-only."
warn "See /tmp/dkms_autoinstall.log for build details."
fi
else
error "dkms autoinstall failed - see /tmp/dkms_autoinstall.log"
warn "Ensure headers for ${running_kernel} are installed (proxmox-headers-*)."
fi
}
# -------------------------------------------------------------------------------------
# MODULE AUTOLOAD
# -------------------------------------------------------------------------------------
write_module_autoload() {
cat > "${MODULES_LOAD_FILE}" << 'MLEOF'
nvidia
nvidia_modeset
nvidia_drm
nvidia_uvm
MLEOF
}
configure_module_autoload() {
section "Configuring Module Autoload"
if [[ -f "$MODULES_LOAD_FILE" ]]; then
ok "Module autoload already configured: $MODULES_LOAD_FILE"
return
fi
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would write ${MODULES_LOAD_FILE}"
return
fi
write_module_autoload
ok "Module autoload configured"
}
# -------------------------------------------------------------------------------------
# PILLAR 2 - DEVICE NODE STABILITY
# -------------------------------------------------------------------------------------
write_node_creation_script() {
cat > "${NODE_SCRIPT}" << 'NODEEOF'
#!/bin/bash
# nvidia-setup-nodes.sh - called by nvidia-setup-nodes.service at sysinit
# Ensures all /dev/nvidia* device nodes exist with correct permissions.
# This runs BEFORE any LXC containers start (see Before= in service unit).
set -euo pipefail
log() { echo "[nvidia-setup-nodes] $*"; }
if ! lsmod | grep -q '^nvidia_uvm'; then
log "Loading nvidia_uvm module..."
if ! modprobe nvidia_uvm 2>/tmp/nvidia_uvm_modprobe.err; then
log "ERROR: failed to load nvidia_uvm - see /tmp/nvidia_uvm_modprobe.err"
cat /tmp/nvidia_uvm_modprobe.err || true
exit 1
fi
fi
for i in $(seq 1 10); do
grep -q 'nvidia-uvm' /proc/devices 2>/dev/null && break
sleep 1
done
UVM_MAJOR="$(awk '$2=="nvidia-uvm"{print $1}' /proc/devices || true)"
if [[ -z "${UVM_MAJOR}" ]]; then
log "ERROR: nvidia-uvm major not found in /proc/devices after 10 seconds"
exit 1
fi
log "nvidia-uvm major: ${UVM_MAJOR}"
if [[ ! -c /dev/nvidia-uvm ]]; then
[[ -e /dev/nvidia-uvm ]] && rm -f /dev/nvidia-uvm
mknod -m 0666 /dev/nvidia-uvm c "${UVM_MAJOR}" 0
log "Created /dev/nvidia-uvm"
fi
if [[ ! -c /dev/nvidia-uvm-tools ]]; then
[[ -e /dev/nvidia-uvm-tools ]] && rm -f /dev/nvidia-uvm-tools
mknod -m 0666 /dev/nvidia-uvm-tools c "${UVM_MAJOR}" 1
log "Created /dev/nvidia-uvm-tools"
fi
chmod 0666 /dev/nvidia* 2>/dev/null || true
chmod 0666 /dev/nvidia-uvm* 2>/dev/null || true
log "All nvidia device nodes verified."
NODEEOF
chmod 755 "${NODE_SCRIPT}"
}
install_node_creation_script() {
info "Installing node creation script: ${NODE_SCRIPT}"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would write ${NODE_SCRIPT}"
return
fi
write_node_creation_script
ok "Node creation script installed"
}
write_node_service() {
cat > "${NODE_SERVICE}" << 'SVCEOF'
[Unit]
Description=NVIDIA Device Node Setup (must run before LXC containers)
Documentation=https://github.com/braedach/homelab
After=systemd-modules-load.service
Before=lxc.service
Before=pve-container@.service
ConditionPathExists=/proc/devices
DefaultDependencies=no
[Service]
Type=oneshot
RemainAfterExit=yes
ExecStart=/usr/local/sbin/nvidia-setup-nodes.sh
StandardOutput=journal
StandardError=journal
[Install]
WantedBy=sysinit.target
SVCEOF
}
install_node_service() {
info "Installing systemd service: ${NODE_SERVICE}"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would write ${NODE_SERVICE}"
return
fi
write_node_service
ok "Service unit installed"
}
write_udev_rules() {
cat > "${UVM_RULE_FILE}" << 'UDEVEOF'
# nvidia-uvm device permissions - managed by setup-gpu-pxe.sh
KERNEL=="nvidia-uvm", MODE="0666"
KERNEL=="nvidia-uvm-tools", MODE="0666"
KERNEL=="nvidia*", MODE="0666"
UDEVEOF
}
install_udev_rules() {
info "Installing udev rules: ${UVM_RULE_FILE}"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would write ${UVM_RULE_FILE}"
return
fi
write_udev_rules
ok "udev rules installed"
udevadm control --reload-rules 2>/dev/null || true
udevadm trigger 2>/dev/null || true
}
enable_nvidia_persistenced() {
section "Enabling nvidia-persistenced"
if ! systemctl list-unit-files nvidia-persistenced.service &>/dev/null; then
warn "nvidia-persistenced.service not present - package may not be installed yet."
warn "It is installed by install_nvidia_backports; re-run after a reboot if missing."
return
fi
if systemctl is-enabled nvidia-persistenced &>/dev/null; then
ok "nvidia-persistenced already enabled"
else
run "systemctl enable nvidia-persistenced 2>/dev/null || true"
run "systemctl start nvidia-persistenced 2>/dev/null || true"
ok "nvidia-persistenced enabled"
fi
}
setup_device_stability() {
section "Setting Up Device Node Stability (Pillar 2)"
install_node_creation_script
install_node_service
install_udev_rules
if [[ "${DRY_RUN}" -eq 0 ]]; then
systemctl daemon-reload
systemctl enable nvidia-setup-nodes.service
systemctl restart nvidia-setup-nodes.service || true
ok "nvidia-setup-nodes.service enabled and started"
else
info "[dry-run] systemctl daemon-reload && systemctl enable nvidia-setup-nodes.service"
fi
enable_nvidia_persistenced
}
# -------------------------------------------------------------------------------------
# MODULE LOAD + VERIFICATION
# -------------------------------------------------------------------------------------
warm_up_gpu() {
# Touch the GPU so any idle-unloaded modules reload before we sample lsmod.
if command -v nvidia-smi &>/dev/null; then
nvidia-smi >/dev/null 2>&1 || true
fi
}
load_and_verify_modules() {
section "Loading and Verifying NVIDIA Modules"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would load and verify nvidia modules"
return
fi
local modules=(nvidia nvidia_modeset nvidia_drm nvidia_uvm)
local failed=()
for mod in "${modules[@]}"; do
if lsmod | grep -q "^${mod}[[:space:]]"; then
ok "Module loaded: $mod"
else
info "Loading module: $mod"
if modprobe "$mod" 2>/tmp/modprobe_err_${mod}.log; then
ok "Module loaded: $mod"
else
fail "Module failed: $mod (see /tmp/modprobe_err_${mod}.log)"
failed+=("$mod")
fi
fi
done
if [[ ${#failed[@]} -gt 0 ]]; then
warn "Some modules failed to load: ${failed[*]}"
warn "This is expected if a reboot is needed after DKMS build."
warn "Reboot and re-run with --check-only to verify."
fi
}
run_nvidia_smi_check() {
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] Would run nvidia-smi"
return
fi
section "nvidia-smi Verification"
if command -v nvidia-smi &>/dev/null; then
if nvidia-smi; then
ok "nvidia-smi successful"
else
warn "nvidia-smi returned an error - reboot may be required"
fi
else
warn "nvidia-smi not found - driver may need a reboot to activate"
fi
}
# -------------------------------------------------------------------------------------
# BOOT PIN HELPERS
# -------------------------------------------------------------------------------------
get_pinned_kernel() {
if command -v proxmox-boot-tool &>/dev/null; then
proxmox-boot-tool kernel list 2>/dev/null \
| awk '/^Pinned kernel:/{getline; gsub(/^[ \t]+/,""); print; exit}'
fi
}
pin_running_kernel() {
section "Pinning Boot Kernel (Guard Layer 3)"
local rk; rk="$(uname -r)"
if ! command -v proxmox-boot-tool &>/dev/null; then
warn "proxmox-boot-tool not found - cannot auto-pin."
warn "Ensure your bootloader defaults to ${rk} manually."
return
fi
# Never pin a kernel that has no built NVIDIA module.
if ! dkms status 2>/dev/null | grep -F "$rk" | grep -q installed; then
warn "Running kernel ${rk} has no installed nvidia DKMS module - NOT pinning."
warn "Resolve the driver build first, then pin manually:"
warn " proxmox-boot-tool kernel pin ${rk}"
return
fi
local current_pin; current_pin="$(get_pinned_kernel || true)"
if [[ "$current_pin" == "$rk" ]]; then
ok "Boot kernel already pinned to ${rk}"
return
fi
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] proxmox-boot-tool kernel pin ${rk}"
return
fi
info "Pinning running kernel: ${rk}"
proxmox-boot-tool kernel pin "${rk}" || warn "Pin command returned an error."
ok "Boot kernel pinned to ${rk}"
}
# -------------------------------------------------------------------------------------
# GUARD LAYER 1 - PREFLIGHT GATE
# -------------------------------------------------------------------------------------
# Returns 0 if safe, 2 if an unapproved kernel series would be installed.
do_preflight() {
section "Preflight - Kernel Series Guard (Layer 1)"
info "Approved kernel series: ${APPROVED_KERNEL_SERIES[*]}"
info "Simulating: apt-get full-upgrade ..."
local sim
sim="$(LANG=C apt-get -s full-upgrade 2>/dev/null || true)"
local incoming
incoming="$(echo "$sim" | awk '/^Inst /{print $2}' || true)"
local kernel_incoming=() bad=() selector_moving=0
while IFS= read -r pkg; do
[[ -z "$pkg" ]] && continue
case "$pkg" in
proxmox-default-kernel|proxmox-default-headers) selector_moving=1 ;;
esac
if [[ "$pkg" == proxmox-kernel-* || "$pkg" == proxmox-headers-* ]]; then
kernel_incoming+=("$pkg")
local s; s="$(kernel_series_from_pkg "$pkg")"
if [[ -n "$s" ]] && ! is_approved_series "$s"; then
bad+=("$pkg (series ${s})")
fi
fi
done <<< "$incoming"
if [[ ${#kernel_incoming[@]} -gt 0 ]]; then
info "Kernel/header packages this upgrade would install:"
for p in "${kernel_incoming[@]}"; do info " $p"; done
else
ok "No kernel or header packages in this upgrade."
fi
if [[ "$selector_moving" -eq 1 ]]; then
warn "proxmox-default-kernel/headers would change - the DEFAULT series is moving."
warn "This is exactly how the 7.0 series jump arrived. Inspect carefully."
fi
if [[ ${#bad[@]} -gt 0 ]]; then
echo ""
error "=================================================================="
error " BLOCKED - upgrade would install an UNAPPROVED kernel series"
error "=================================================================="
for b in "${bad[@]}"; do error " $b"; done
error ""
error "Approved series: ${APPROVED_KERNEL_SERIES[*]}"
error "An unapproved series will FAIL the NVIDIA DKMS build, can wedge dpkg,"
error "and can leave a bootable-but-broken kernel as the GRUB default."
error ""
error "DO NOT run 'apt full-upgrade' until you have either:"
error " (a) applied the guard: sudo $SCRIPT_NAME --apply-guard"
error " (holds the offending packages so apt keeps them back), OR"
error " (b) CONFIRMED NVIDIA supports the new series, then approved it"
error " by editing APPROVED_KERNEL_SERIES and running --remove-guard."
error "=================================================================="
return 2
fi
ok "Preflight PASSED - no unapproved kernel series incoming."
ok "Safe to proceed with: apt full-upgrade"
return 0
}
# -------------------------------------------------------------------------------------
# GUARD LAYER 2 - APT HOLDS (+ triggers Layer 3 pin)
# -------------------------------------------------------------------------------------
build_hold_list() {
# Echo (one per line) the packages that should be held:
# - the selector meta-packages (always)
# - any installed kernel/header packages from an unapproved series
local p
for p in "${SELECTOR_PACKAGES[@]}"; do echo "$p"; done
while IFS= read -r pkg; do
[[ -z "$pkg" ]] && continue
local s; s="$(kernel_series_from_pkg "$pkg")"
[[ -z "$s" ]] && continue
if ! is_approved_series "$s"; then echo "$pkg"; fi
done < <(dpkg-query -W -f='${Package}\n' 'proxmox-kernel-*' 'proxmox-headers-*' 2>/dev/null | sort -u || true)
}
apply_kernel_guard() {
section "Applying Kernel Series Guard (Layers 2 + 3)"
info "Approved kernel series: ${APPROVED_KERNEL_SERIES[*]}"
local raw uniq=() seen=" "
raw="$(build_hold_list)"
while IFS= read -r p; do
[[ -z "$p" ]] && continue
if [[ "$seen" != *" $p "* ]]; then uniq+=("$p"); seen+="$p "; fi
done <<< "$raw"
if [[ ${#uniq[@]} -eq 0 ]]; then
warn "No packages resolved for holding (unexpected)."
else
info "Packages to hold (apt will keep these back on upgrade):"
for p in "${uniq[@]}"; do info " $p"; done
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] apt-mark hold ${uniq[*]}"
else
apt-mark hold "${uniq[@]}" || warn "Some holds may have failed (package not installed?)."
ok "Holds applied. 'proxmox-default-kernel' will now show as kept-back."
ok "6.17 security point-updates STILL flow (proxmox-kernel-6.17 is not held)."
fi
fi
pin_running_kernel
}
# -------------------------------------------------------------------------------------
# GUARD - REMOVE
# -------------------------------------------------------------------------------------
remove_kernel_guard() {
section "Removing Kernel Series Guard"
warn "This lifts the apt holds that protect you from an unsupported kernel series."
warn "Only do this once you have CONFIRMED NVIDIA builds against the new series"
warn "AND added that series to APPROVED_KERNEL_SERIES."
echo ""
local held
held="$(apt-mark showhold 2>/dev/null | grep -E '^proxmox-(default|kernel|headers)-' || true)"
if [[ -z "$held" ]]; then
ok "No matching proxmox kernel/header holds present."
return
fi
info "Currently held:"
echo "$held" | while read -r p; do info " $p"; done
echo ""
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] apt-mark unhold ${held//$'\n'/ }"
return
fi
read -r -p "Type 'unhold' to confirm lifting these holds: " confirm
[[ "$confirm" == "unhold" ]] || { info "Cancelled - holds left in place."; return; }
# shellcheck disable=SC2086
apt-mark unhold $held || warn "Some unholds may have failed."
ok "Holds removed. Re-run --preflight BEFORE upgrading."
info "The boot-kernel pin (if set) is unchanged - manage via proxmox-boot-tool."
}
# -------------------------------------------------------------------------------------
# GUARD - STATUS
# -------------------------------------------------------------------------------------
guard_status() {
section "Kernel Guard Status"
echo ""
echo "-- Approved Kernel Series -------------------------------"
info "${APPROVED_KERNEL_SERIES[*]}"
echo ""
echo "-- Running Kernel ---------------------------------------"
info "$(uname -r)"
echo ""
echo "-- apt Holds (Layer 2) ----------------------------------"
local holds
holds="$(apt-mark showhold 2>/dev/null | grep -E '^proxmox-(default|kernel|headers)-' || true)"
if [[ -n "$holds" ]]; then
echo "$holds" | while read -r p; do ok "$p [held]"; done
else
fail "No proxmox kernel/header holds set - guard Layer 2 NOT active."
warn "Apply with: sudo $SCRIPT_NAME --apply-guard"
fi
echo ""
echo "-- Boot Kernel Pin (Layer 3) ----------------------------"
if command -v proxmox-boot-tool &>/dev/null; then
local pinned; pinned="$(get_pinned_kernel || true)"
if [[ -n "$pinned" && "$pinned" != "None." ]]; then
ok "Pinned kernel: ${pinned}"
[[ "$pinned" == "$(uname -r)" ]] || warn "Pinned kernel differs from running kernel."
else
fail "No boot kernel pinned - guard Layer 3 NOT active."
warn "Apply with: sudo $SCRIPT_NAME --apply-guard"
fi
else
skip "proxmox-boot-tool not available - cannot report pin state."
fi
echo ""
echo "-- Installed Proxmox Kernels ----------------------------"
local pk
while IFS= read -r pk; do
[[ -z "$pk" ]] && continue
local s; s="$(kernel_series_from_pkg "$pk")"
if [[ -n "$s" ]] && is_approved_series "$s"; then
ok "$pk (series ${s}, approved)"
elif [[ -n "$s" ]]; then
warn "$pk (series ${s}, NOT approved - should be held)"
fi
done < <(dpkg-query -W -f='${Package}\n' 'proxmox-kernel-[0-9]*' 2>/dev/null | sort -u || true)
echo ""
echo "-- Stale Boot Entries -----------------------------------"
local se; se="$(stale_boot_kernels || true)"
if [[ -n "$se" ]]; then
echo "$se" | while read -r k; do warn "$k (boot entry present, package not installed) - run --cleanup-boot"; done
else
ok "None."
fi
}
# -------------------------------------------------------------------------------------
# PILLAR 3 - LXC CONTAINER CONFIGURATION
# -------------------------------------------------------------------------------------
print_lxc_config() {
local vmid="${1:-<VMID>}"
echo ""
echo "======================================================="
echo " LXC GPU Passthrough Configuration"
echo " Container: ${vmid}"
echo " File: /etc/pve/lxc/${vmid}.conf"
echo "======================================================="
echo ""
echo "# NVIDIA GPU passthrough - generated by setup-gpu-pxe.sh v${SCRIPT_VERSION}"
echo "# Uses Proxmox 8.1+ dev* syntax (handles device type detection automatically)"
echo "# gid=44 is the 'video' group on Debian-based systems"
echo "# Verify with: getent group video (inside the container)"
echo "#"
echo "dev0: /dev/nvidia0,gid=${LXC_VIDEO_GID}"
echo "dev1: /dev/nvidiactl,gid=${LXC_VIDEO_GID}"
echo "dev2: /dev/nvidia-modeset,gid=${LXC_VIDEO_GID}"
echo "dev3: /dev/nvidia-uvm,gid=${LXC_VIDEO_GID}"
echo "dev4: /dev/nvidia-uvm-tools,gid=${LXC_VIDEO_GID}"
echo "dev5: /dev/nvidia-caps/nvidia-cap1,gid=${LXC_VIDEO_GID}"
echo "dev6: /dev/nvidia-caps/nvidia-cap2,gid=${LXC_VIDEO_GID}"
echo ""
echo "# Also recommended: container startup delay to allow host nodes to settle"
echo "# startup: order=2,up=15"
echo ""
echo "======================================================="
echo ""
echo "NOTES:"
echo " 1. Do NOT install the full NVIDIA driver package inside the container."
echo " Only install userspace libraries (libnvidia-compute-*) if needed."
echo " 2. The dev* directive handles cgroup2 permissions automatically."
echo " You do NOT need separate lxc.cgroup2.devices.allow lines."
echo " 3. If you have multiple GPUs (e.g. dual RTX), increment the dev* index"
echo " and add: dev7: /dev/nvidia1,gid=${LXC_VIDEO_GID}"
echo " 4. After applying config, restart the container:"
echo " pct stop ${vmid} && pct start ${vmid}"
echo " 5. Verify inside the container:"
echo " ls -la /dev/nvidia*"
echo " nvidia-smi"
echo ""
}
# -------------------------------------------------------------------------------------
# PURGE
# -------------------------------------------------------------------------------------
do_purge() {
section "Purging All NVIDIA Components"
warn "This will remove ALL NVIDIA packages and configuration."
read -r -p "Are you sure? (yes/no): " confirm
[[ "$confirm" == "yes" ]] || { info "Purge cancelled."; exit 0; }
run "systemctl stop nvidia-setup-nodes.service 2>/dev/null || true"
run "systemctl disable nvidia-setup-nodes.service 2>/dev/null || true"
run "systemctl stop nvidia-persistenced 2>/dev/null || true"
run "systemctl disable nvidia-persistenced 2>/dev/null || true"
run "rm -f '${NODE_SERVICE}' '${NODE_SCRIPT}' '${UVM_RULE_FILE}' '${MODULES_LOAD_FILE}' '${NOUVEAU_BLACKLIST}'"
if [[ "${DRY_RUN}" -eq 0 ]]; then
systemctl daemon-reload
udevadm control --reload-rules 2>/dev/null || true
fi
local nvidia_pkgs
nvidia_pkgs="$(dpkg -l '*nvidia*' '*libnvidia*' 2>/dev/null | awk '/^ii/{print $2}' || true)"
if [[ -n "$nvidia_pkgs" ]]; then
info "Removing packages:"
echo "$nvidia_pkgs" | while read -r p; do info " $p"; done
if [[ "${DRY_RUN}" -eq 0 ]]; then
# shellcheck disable=SC2086
DEBIAN_FRONTEND=noninteractive apt-get purge -y $nvidia_pkgs || true
DEBIAN_FRONTEND=noninteractive apt-get autoremove -y || true
else
info "[dry-run] apt-get purge -y ${nvidia_pkgs//$'\n'/ }"
fi
fi
ok "Purge complete. You may want to reboot."
info "Note: --purge does NOT touch kernel guard holds. Use --remove-guard for those."
}
# -------------------------------------------------------------------------------------
# HEALTH CHECK / --check-only
# -------------------------------------------------------------------------------------
do_check() {
section "NVIDIA System Health Check"
# Warm the GPU first so idle-unloaded modules reload before we sample state.
warm_up_gpu
local smi_ok=0
if command -v nvidia-smi &>/dev/null && nvidia-smi &>/dev/null; then
smi_ok=1
fi
echo ""
echo "-- Running Kernel ---------------------------------------"
info "$(uname -r)"
echo ""
echo "-- Kernel Modules ---------------------------------------"
for mod in nvidia nvidia_modeset nvidia_drm nvidia_uvm; do
if lsmod | grep -q "^${mod}[[:space:]]"; then
ok "$mod loaded"
elif [[ "$smi_ok" -eq 1 ]]; then
skip "$mod not currently loaded (driver functional; loads on access)"
else
fail "$mod NOT loaded"
fi
done
echo ""
echo "-- Device Nodes -----------------------------------------"
for dev in /dev/nvidia0 /dev/nvidiactl /dev/nvidia-modeset /dev/nvidia-uvm /dev/nvidia-uvm-tools; do
if [[ -c "$dev" ]]; then
local info_str; info_str="$(ls -la "$dev" 2>/dev/null)"
ok "$dev -> $info_str"
elif [[ -e "$dev" ]]; then
fail "$dev EXISTS but is NOT a character device (stub file - timing bug)"
else
fail "$dev MISSING"
fi
done
for cap in /dev/nvidia-caps/nvidia-cap1 /dev/nvidia-caps/nvidia-cap2; do
if [[ -c "$cap" ]]; then
ok "$cap -> $(ls -la "$cap" 2>/dev/null)"
else
skip "$cap not found (normal on GPUs without MIG/caps support)"
fi
done
echo ""
echo "-- systemd Services -------------------------------------"
for svc in nvidia-setup-nodes.service nvidia-persistenced.service; do
local state; state="$(systemctl is-active "$svc" 2>/dev/null || echo "inactive")"
local enabled; enabled="$(systemctl is-enabled "$svc" 2>/dev/null || echo "disabled")"
if [[ "$state" == "active" && "$enabled" == "enabled" ]]; then
ok "$svc [active/enabled]"
else
fail "$svc [${state}/${enabled}]"
fi
done
echo ""
echo "-- DKMS Status (running kernel = $(uname -r)) -----------"
if command -v dkms &>/dev/null; then
local rk; rk="$(uname -r)"
dkms status | while IFS= read -r line; do
if echo "$line" | grep -q "installed"; then
ok "$line"
else
fail "$line"
fi
done
if dkms status 2>/dev/null | grep -F "$rk" | grep -q "installed"; then
ok "nvidia module present for running kernel ${rk}"
else
fail "no installed nvidia module for running kernel ${rk} - run a full install or --force-rebuild"
fi
else
skip "dkms not installed"
fi
echo ""
echo "-- nvidia-smi -------------------------------------------"
if command -v nvidia-smi &>/dev/null; then
nvidia-smi || warn "nvidia-smi failed"
else
fail "nvidia-smi not found"
fi
echo ""
echo "-- Kernel Guard -----------------------------------------"
local holds pin
holds="$(apt-mark showhold 2>/dev/null | grep -E '^proxmox-(default|kernel|headers)-' || true)"
if [[ -n "$holds" ]]; then
ok "apt holds active (Layer 2):"
echo "$holds" | while read -r p; do ok " $p"; done
else
fail "No proxmox kernel/header apt holds - guard Layer 2 NOT active (run --apply-guard)"
fi
if command -v proxmox-boot-tool &>/dev/null; then
pin="$(get_pinned_kernel || true)"
if [[ -n "$pin" && "$pin" != "None." ]]; then
ok "Boot kernel pinned (Layer 3): ${pin}"
else
fail "No boot kernel pinned - guard Layer 3 NOT active (run --apply-guard)"
fi
fi
local sb; sb="$(stale_boot_kernels || true)"
if [[ -n "$sb" ]]; then
echo "$sb" | while read -r k; do warn "stale boot entry: $k - run --cleanup-boot"; done
else
ok "No stale boot entries"
fi
echo ""
echo "-- Installed Files --------------------------------------"
for f in "$NODE_SERVICE" "$NODE_SCRIPT" "$UVM_RULE_FILE" "$NOUVEAU_BLACKLIST" "$MODULES_LOAD_FILE"; do
if [[ -f "$f" ]]; then
ok "$f"
else
fail "$f MISSING"
fi
done
echo ""
print_lxc_config "YOUR_VMID"
}
# -------------------------------------------------------------------------------------
# FORCE REBUILD
# -------------------------------------------------------------------------------------
do_force_rebuild() {
section "Force Rebuilding DKMS Modules"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] dkms autoinstall --force"
return
fi
info "Forcing DKMS rebuild for all kernels..."
dkms autoinstall --force 2>&1 | tee /tmp/dkms_rebuild.log || true
ok "Force rebuild complete. Check /tmp/dkms_rebuild.log for details."
}
# -------------------------------------------------------------------------------------
# HELP
# -------------------------------------------------------------------------------------
show_help() {
cat <<EOF
${BOLD}setup-gpu-pxe.sh v${SCRIPT_VERSION}${RESET}
Proxmox VE NVIDIA Driver Host Installer + LXC GPU Configurator + Kernel Guard
${BOLD}USAGE${RESET}
sudo $SCRIPT_NAME [OPTION]
${BOLD}INSTALL / VERIFY${RESET}
(none) Full install - drivers, services, nodes, THEN applies guard
--check-only System + GPU health (also reports guard status)
--force-rebuild Force DKMS module rebuild (after a kernel update)
--lxc-config [ID] Print LXC container config snippet (optional VMID)
${BOLD}KERNEL GUARD${RESET}
--preflight Simulate full-upgrade; BLOCK if an unapproved series is
incoming. Run this BEFORE 'apt full-upgrade'.
--apply-guard apt-mark hold the series selector + unapproved-series
packages, then pin the running kernel.
--guard-status Show approved series, apt holds, and boot pin.
--remove-guard Lift the apt holds (after approving a new series).
--repoint-selector [VER]
Move proxmox-default-kernel/headers to an approved-series
version and re-hold (the "get off 7.0 as default" fix).
--cleanup-boot Reconcile the ESP and remove stale boot entries.
--prune-dkms Remove DKMS builds for kernels no longer installed.
${BOLD}MAINTENANCE${RESET}
--purge Remove all NVIDIA components (does not touch holds)
--dry-run Preview any action without making changes
--help Show this help
${BOLD}APPROVED KERNEL SERIES${RESET} (edit APPROVED_KERNEL_SERIES near the top)
${APPROVED_KERNEL_SERIES[*]}
${BOLD}KERNEL UPDATE SOP (manual, production)${RESET}
The boot pin holds you on the current kernel, so a new kernel does NOT auto-boot.
Pin the NEW kernel BEFORE rebooting so a SINGLE reboot lands on it.
1. apt update
2. sudo $SCRIPT_NAME --preflight hard gate; STOP if it prints BLOCKED
3. apt full-upgrade installs new kernel; DKMS builds NVIDIA
4. dkms status confirm NEW kernel shows 'installed'
(do this while still on the OLD kernel)
5. proxmox-boot-tool kernel pin <NEW> re-pin BEFORE rebooting
6. reboot
7. uname -r confirm you are on <NEW>
8. sudo $SCRIPT_NAME --check-only verify GPU on the new kernel
9. sudo $SCRIPT_NAME --apply-guard reconfirm holds + pin (running kernel)
10. start passthrough LXCs; nvidia-smi inside each
Optional cleanup, once the new kernel is proven and a spare remains:
- sudo $SCRIPT_NAME --prune-dkms drop DKMS builds for removed kernels
- sudo $SCRIPT_NAME --cleanup-boot clear stale boot entries
EOF
}
# -------------------------------------------------------------------------------------
# BOOT ENTRY / SELECTOR HELPERS (v4.1.0)
# -------------------------------------------------------------------------------------
# Kernel version strings (matching uname -r) for installed proxmox-kernel packages.
installed_kernel_versions() {
local pkg v
while IFS= read -r pkg; do
[[ -z "$pkg" ]] && continue
v="${pkg#proxmox-kernel-}"
v="${v%-signed}"
echo "$v"
done < <(dpkg-query -W -f='${Package}\n' 'proxmox-kernel-[0-9]*' 2>/dev/null \
| grep -E '\-pve(-signed)?$' | sort -u || true)
}
# Kernels registered for boot in proxmox-boot-tool's "Automatically selected" list.
boot_listed_kernels() {
command -v proxmox-boot-tool &>/dev/null || return 0
proxmox-boot-tool kernel list 2>/dev/null \
| awk '/[Aa]utomatically selected kernels:/{f=1;next} /Pinned kernel:/{f=0} f&&NF{gsub(/^[ \t]+/,"");print}'
}
# Boot-listed kernels whose package is NOT installed, excluding running + pinned.
stale_boot_kernels() {
command -v proxmox-boot-tool &>/dev/null || return 0
local running pinned inst k
running="$(uname -r)"
pinned="$(get_pinned_kernel || true)"
inst=" $(installed_kernel_versions | tr '\n' ' ') "
while IFS= read -r k; do
[[ -z "$k" ]] && continue
[[ "$k" == "$running" ]] && continue
[[ "$k" == "$pinned" ]] && continue
[[ "$inst" == *" $k "* ]] && continue
echo "$k"
done < <(boot_listed_kernels)
}
# Emit "VERSION SERIES" for each available proxmox-default-kernel version.
list_selector_versions() {
apt-cache show proxmox-default-kernel 2>/dev/null | awk '
/^Version:/ { ver=$2 }
/^Depends:/ {
if (match($0, /proxmox-kernel-[0-9]+\.[0-9]+/)) {
s=substr($0, RSTART, RLENGTH); sub(/proxmox-kernel-/,"",s);
print ver, s
}
}'
}
# -------------------------------------------------------------------------------------
# --cleanup-boot : reconcile ESP and drop stale boot entries
# -------------------------------------------------------------------------------------
cleanup_boot() {
section "Boot Kernel Cleanup"
if ! command -v proxmox-boot-tool &>/dev/null; then
warn "proxmox-boot-tool not found - nothing to reconcile."
return
fi
local running pinned
running="$(uname -r)"; pinned="$(get_pinned_kernel || true)"
info "Running kernel: ${running}"
info "Pinned kernel: ${pinned:-<none>}"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] proxmox-boot-tool clean"
else
info "Reconciling ESP (proxmox-boot-tool clean)..."
proxmox-boot-tool clean || warn "clean returned an error."
fi
local stale=() k
while IFS= read -r k; do [[ -n "$k" ]] && stale+=("$k"); done < <(stale_boot_kernels)
if [[ ${#stale[@]} -eq 0 ]]; then
ok "No stale boot entries (every listed kernel is installed / running / pinned)."
else
warn "Stale boot entries (listed for boot but package not installed):"
for k in "${stale[@]}"; do warn " $k"; done
if [[ "${DRY_RUN}" -eq 1 ]]; then
for k in "${stale[@]}"; do info "[dry-run] proxmox-boot-tool kernel remove $k"; done
else
for k in "${stale[@]}"; do
info "Removing stale boot entry: $k"
proxmox-boot-tool kernel remove "$k" || warn " remove failed for $k"
done
fi
fi
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] proxmox-boot-tool refresh"
else
info "Refreshing boot configuration..."
proxmox-boot-tool refresh || warn "refresh returned an error."
fi
echo ""
info "Current kernel list:"
proxmox-boot-tool kernel list 2>/dev/null || true
}
# -------------------------------------------------------------------------------------
# --prune-dkms : remove DKMS builds for kernels that are no longer installed
# -------------------------------------------------------------------------------------
# After a kernel update, an old kernel's package may be gone while its NVIDIA DKMS
# build lingers in 'dkms status'. This removes those obsolete builds. It NEVER touches
# the build for the running kernel or for any kernel whose package is still installed.
prune_dkms() {
section "Pruning Obsolete DKMS Builds"
if ! command -v dkms &>/dev/null; then
warn "dkms not found - nothing to do."
return
fi
local running inst
running="$(uname -r)"
inst=" $(installed_kernel_versions | tr '\n' ' ') "
# dkms status line: "nvidia-current/550.163.01, 6.17.4-2-pve, x86_64: installed"
local obsolete=() line mod kern
while IFS= read -r line; do
[[ -z "$line" ]] && continue
mod="$(echo "$line" | awk -F, '{print $1}' | xargs)" # nvidia-current/550.163.01
kern="$(echo "$line" | awk -F, '{print $2}' | xargs)" # 6.17.4-2-pve
[[ -z "$mod" || -z "$kern" ]] && continue
[[ "$kern" =~ ^[0-9]+\.[0-9]+ ]] || continue # sanity: looks like a version
[[ "$kern" == "$running" ]] && continue # never the running kernel
[[ "$inst" == *" $kern "* ]] && continue # never an installed kernel
obsolete+=("${mod}|${kern}")
done < <(dkms status 2>/dev/null || true)
if [[ ${#obsolete[@]} -eq 0 ]]; then
ok "No obsolete DKMS builds (every build is for an installed or running kernel)."
return
fi
info "Obsolete DKMS builds (kernel no longer installed):"
local entry
for entry in "${obsolete[@]}"; do
info " ${entry%|*} for kernel ${entry#*|}"
done
if [[ "${DRY_RUN}" -eq 1 ]]; then
for entry in "${obsolete[@]}"; do
info "[dry-run] dkms remove ${entry%|*} -k ${entry#*|}"
done
return
fi
read -r -p "Remove the DKMS builds listed above? Type 'yes': " c
[[ "$c" == "yes" ]] || { info "Cancelled - no changes made."; return; }
for entry in "${obsolete[@]}"; do
mod="${entry%|*}"; kern="${entry#*|}"
info "Removing: ${mod} for kernel ${kern}"
dkms remove "${mod}" -k "${kern}" || warn " remove failed for ${mod} / ${kern}"
done
ok "Obsolete DKMS builds removed."
info "Current dkms status:"
dkms status 2>/dev/null || true
}
# -------------------------------------------------------------------------------------
# --repoint-selector [VER] : move proxmox-default-kernel/headers to an approved series
# -------------------------------------------------------------------------------------
# Automates the manual fix used to get OFF the 7.0 default without touching proxmox-ve:
# apt-get install proxmox-default-kernel=2.0.2 proxmox-default-headers=2.0.2
# apt-mark hold proxmox-default-kernel proxmox-default-headers
# Downgrading the SELECTOR meta orphans the unapproved-series kernel, which can then be
# removed with 'apt-get autoremove' + '--cleanup-boot'. proxmox-ve stays satisfied
# because the approved-series selector still fulfils its dependency.
do_repoint_selector() {
section "Repoint Default-Kernel Selector to an Approved Series"
local want="${REPOINT_VERSION:-}"
local rows; rows="$(list_selector_versions | sort -rV || true)"
if [[ -z "$rows" ]]; then
warn "Could not read proxmox-default-kernel versions from apt-cache."
warn "Run 'apt update' first, then retry."
return
fi
info "Available proxmox-default-kernel versions (version -> kernel series):"
while read -r v s; do
[[ -z "$v" ]] && continue
if is_approved_series "$s"; then ok " $v -> $s (approved)"; else warn " $v -> $s (NOT approved)"; fi
done <<< "$rows"
local cur cur_series
cur="$(dpkg-query -W -f='${Version}' proxmox-default-kernel 2>/dev/null || true)"
cur_series="$(echo "$rows" | awk -v v="$cur" '$1==v{print $2; exit}')"
echo ""
info "Currently installed: ${cur:-<none>} (series ${cur_series:-unknown})"
if [[ -n "$cur_series" ]] && is_approved_series "$cur_series"; then
ok "Selector already points at an approved series - nothing to do."
return
fi
# Choose target: explicit VER, else highest available approved-series version.
local target="$want"
if [[ -z "$target" ]]; then
while read -r v s; do
if is_approved_series "$s"; then target="$v"; break; fi # rows sorted desc
done <<< "$rows"
fi
if [[ -z "$target" ]]; then
error "No available selector version depends on an approved series (${APPROVED_KERNEL_SERIES[*]})."
error "Either an approved-series meta isn't in your repos, or APPROVED_KERNEL_SERIES needs updating."
return
fi
local target_series; target_series="$(echo "$rows" | awk -v v="$target" '$1==v{print $2; exit}')"
if [[ -z "$target_series" ]]; then
error "Version ${target} not found among available proxmox-default-kernel versions."
return
fi
if ! is_approved_series "$target_series"; then
error "Refusing: target ${target} depends on series ${target_series}, which is NOT approved."
return
fi
info "Target: proxmox-default-kernel=${target} / proxmox-default-headers=${target} (series ${target_series})"
if [[ "${DRY_RUN}" -eq 1 ]]; then
info "[dry-run] apt-mark unhold proxmox-default-kernel proxmox-default-headers"
info "[dry-run] apt-get install --allow-downgrades proxmox-default-kernel=${target} proxmox-default-headers=${target}"
info "[dry-run] apt-mark hold proxmox-default-kernel proxmox-default-headers"
return
fi
warn "apt will show its plan next. REVIEW IT: it must NOT remove proxmox-ve or any"
warn "approved-series (${APPROVED_KERNEL_SERIES[*]}) kernel. Answer 'n' at apt if it does."
read -r -p "Proceed to repoint selectors to ${target}? Type 'yes': " c
[[ "$c" == "yes" ]] || { info "Cancelled - no changes made."; return; }
apt-mark unhold proxmox-default-kernel proxmox-default-headers 2>/dev/null || true
local ok_install=0
if DEBIAN_FRONTEND=noninteractive apt-get install --allow-downgrades \
"proxmox-default-kernel=${target}" "proxmox-default-headers=${target}"; then
ok_install=1
fi
# Always restore protective holds, whatever happened above.
apt-mark hold proxmox-default-kernel proxmox-default-headers 2>/dev/null || true
if [[ "$ok_install" -eq 1 ]]; then
ok "Selectors repointed to ${target} and re-held."
info "Next steps to finish clearing the old series:"
info " apt-get autoremove # drop now-orphaned unapproved kernels"
info " sudo $SCRIPT_NAME --cleanup-boot # clear stale boot entries"
else
warn "Downgrade did not complete (aborted or failed). Selectors re-held at current version."
warn "No harm done - the guard state is intact. Review the apt output above."
fi
}
# -------------------------------------------------------------------------------------
# ARGUMENT PARSING
# -------------------------------------------------------------------------------------
parse_args() {
while [[ $# -gt 0 ]]; do
case "$1" in
--dry-run) DRY_RUN=1 ;;
--purge) PURGE=1 ;;
--force-rebuild) FORCE_REBUILD=1 ;;
--check-only) CHECK_ONLY=1 ;;
--preflight) PREFLIGHT_ONLY=1 ;;
--apply-guard) APPLY_GUARD_ONLY=1 ;;
--remove-guard) REMOVE_GUARD_ONLY=1 ;;
--guard-status) GUARD_STATUS_ONLY=1 ;;
--cleanup-boot) CLEANUP_BOOT_ONLY=1 ;;
--prune-dkms) PRUNE_DKMS_ONLY=1 ;;
--repoint-selector)
REPOINT_SELECTOR_ONLY=1
if [[ $# -gt 1 && "$2" =~ ^[0-9] ]]; then REPOINT_VERSION="$2"; shift; fi
;;
--lxc-config)
LXC_CONFIG_ONLY=1
if [[ $# -gt 1 && "$2" =~ ^[0-9]+$ ]]; then
LXC_VMID="$2"; shift
fi
;;
--help|-h) show_help; exit 0 ;;
*)
error "Unknown argument: $1"
show_help
exit 1
;;
esac
shift
done
}
# -------------------------------------------------------------------------------------
# CLEANUP TRAP
# -------------------------------------------------------------------------------------
cleanup() {
local exit_code=$?
if [[ $exit_code -ne 0 && $exit_code -ne 2 ]]; then
warn "Script exited with code ${exit_code}."
warn "Partial installation may have occurred."
warn "Check the output above, then re-run or use --purge to reset."
fi
}
trap cleanup EXIT
# -------------------------------------------------------------------------------------
# MAIN
# -------------------------------------------------------------------------------------
main() {
parse_args "$@"
check_root "$@"
echo ""
echo -e "${BOLD}${CYAN}setup-gpu-pxe.sh v${SCRIPT_VERSION} - Proxmox VE NVIDIA Driver Installer + Kernel Guard${RESET}"
echo -e "Target: Proxmox VE 9.x / Debian 13 (Trixie)"
echo -e "Approved kernel series: ${APPROVED_KERNEL_SERIES[*]}"
[[ "${DRY_RUN}" -eq 1 ]] && echo -e "${YELLOW}*** DRY RUN MODE - no changes will be made ***${RESET}"
echo ""
# Short-circuit modes
if [[ "${LXC_CONFIG_ONLY}" -eq 1 ]]; then
print_lxc_config "${LXC_VMID}"; exit 0
fi
if [[ "${PREFLIGHT_ONLY}" -eq 1 ]]; then
do_preflight || exit $? # exit 2 on block
exit 0
fi
if [[ "${GUARD_STATUS_ONLY}" -eq 1 ]]; then
guard_status; exit 0
fi
if [[ "${CLEANUP_BOOT_ONLY}" -eq 1 ]]; then
cleanup_boot; exit 0
fi
if [[ "${PRUNE_DKMS_ONLY}" -eq 1 ]]; then
prune_dkms; exit 0
fi
if [[ "${REPOINT_SELECTOR_ONLY}" -eq 1 ]]; then
do_repoint_selector; exit 0
fi
if [[ "${APPLY_GUARD_ONLY}" -eq 1 ]]; then
apply_kernel_guard; exit 0
fi
if [[ "${REMOVE_GUARD_ONLY}" -eq 1 ]]; then
remove_kernel_guard; exit 0
fi
if [[ "${CHECK_ONLY}" -eq 1 ]]; then
do_check; exit 0
fi
if [[ "${PURGE}" -eq 1 ]]; then
do_purge; exit 0
fi
if [[ "${FORCE_REBUILD}" -eq 1 ]]; then
do_force_rebuild; exit 0
fi
# Full install sequence
check_prerequisites
detect_nvidia_gpu
check_secure_boot
blacklist_nouveau
ensure_debian_sources # non-free + trixie-backports
install_nvidia_backports # nvidia-kernel-dkms + nvidia-driver + persistenced
build_dkms_all_kernels # verify DKMS + self-heal running kernel
configure_module_autoload
setup_device_stability # Pillar 2 - boot ordering + persistence
load_and_verify_modules
run_nvidia_smi_check
apply_kernel_guard # Guard Layers 2 + 3
section "Installation Complete"
echo ""
ok "NVIDIA drivers installed (trixie-backports)"
ok "nvidia-setup-nodes.service enabled (runs before LXC at boot)"
ok "nvidia-persistenced installed and enabled"
ok "Kernel guard applied (apt holds + boot pin)"
echo ""
info "Note: a normal re-run VERIFIES the DKMS build and rebuilds only if the"
info "running kernel lacks a module. Before EVERY 'apt full-upgrade', run:"
info " sudo $SCRIPT_NAME --preflight"
echo ""
echo -e "${BOLD}NEXT STEPS:${RESET}"
echo " 1. Reboot the Proxmox host (if this was a fresh driver install)"
echo " 2. Verify: sudo $SCRIPT_NAME --check-only"
echo " 3. Get container config: sudo $SCRIPT_NAME --lxc-config <VMID>"
echo " 4. Apply config to /etc/pve/lxc/<VMID>.conf"
echo " 5. Restart containers: pct stop <VMID> && pct start <VMID>"
echo ""
print_lxc_config "YOUR_VMID"
}
main "$@"This should work fine but you are advised I have a dated card that with drivers that are not supported on version 7 of the new Kernel.
#enoughsaid
